Magnetic separator is mainly used to separate the iron containing workpieces from the abrasive media after finishing processing. It is widely used in large quantity of surface processing of parts. This machine improves the production efficiency by automatically and quickly separating the workpieces from the similar size of abrasive media.
Features:
1. Adopt demagnetizer for demagnetizing the magnetized workpiece.
2. The height of component for separation is adjustable for different polishing equipment.
3. Conveyor is speed adjustable controlled by VFD.
4. Adopt universal wheels at the bottom of the equipment, which makes it easy be moved to different work site.
| Model | MGS300 | MGS400 | MGS600 |
| Drum wid,mm | 185 | 300 | 360 |
| Conveyor motor, kW | 0.55 | 0.75 | 0.75 |
| Conveyor speed, m/s | 0-0.5 | ||
| Magnetic pick up adjusting height,mm | 400 | 450 | |
| Lift motor,kW | 0.55 | ||
| De-magnetic device | TC-2 | ||
| Size,mm | 1514×750×1900 | 1640x800x2030 | 1700x1200x2330 |
| Weight, kg | 370 | 480 | 550 |
